SENDIG S909Z-6 Machine Condition Checker

Specifications

♦ Accuracy + 5% +2 digits

♦ Measurement Range & Frequency response :

Acceleration: 0.1 to 100 m/s2 / 0.01 to 10g / 10Hz~1kHz

Velocity:0.1 to 250 mm/s / 0.01 to 15 inch/s / 10Hz~1000Hz

Displacement: 1 to 3000 µm / 0.03 to 120 mil / 10Hz~500Hz

Enveloped Acceleration: 0.1 to 25 unit / 5Hz~2kHz demodulated from 3kHz~10kHz

Temperature:-33 to 220 ℃ / -27.4 to 428 oF

♦ Battery: 1/2 AA, 3.6V, 20-29mA, >100 hours of continuous operation.

♦ Pickup: Integrated accelerometer with extension stinger

♦ Dimensions: 110x35x17 mm; Weight: 100 g (Including battery)

Datasheet
