Measurem entMethods
Temperature:Semiconductor Sensor
Humidity:High Molecular Electrostatic Capacity Sensor
Measurement
RangesTemperature:-20 to 50℃ / -4 to 122°F , -20 to 80℃ / -4 to 176°F (with sensor Extension Cable)
Humidily:-20 to 90%RH (No Condensation)
0 to 100%RH (with Sensor Extension Cable，No Condensation)
Display(LCD)
Resolution 0.1℃ / O.1°F O.1%RH
Temperature:-20 to 80℃ / -4 to 176°F
Humidity:0 to 100%RH
Others:Dew Point (-80 to 80℃ / -112 to 170°F)
:Absolute Humidity (0 to 290g/m²)
:LCD Display Battery Checker，Chart Speed，Setup Mode，etc
Recording (Chart form)
Chart Paper Z-Fold Type，12m/ 39.37feet (Length) 113mm /4.44inch (Width)
Working Width 100mm (3.93inch) for record both Temperature and Humidity
Feeding Sprocket
Feeding Accuracy ±3 mm / 0.12inch (at 12m / 39.37 feet. Long Recording)
Accuracy
Temperature ±1.0℃ / ±1.8°F at 0 to 50℃ /32 to 122°F
Humidity ± 3% RH (at 25℃ /77F)*Accuracy Guarantee Range on Humidity is 10 to 90%RH
Calibralion
Temperature 1 Point
Humidity 1 or 2 Point
Power Requirement LR20，1.5V x 4pcs, Input 9V 500mA
Dimension W x H x D (mm / inch): 300 x 245 x 105 mm / 11.8 x 9.6 x 4.1 inch
Weight: 2.1kg 4.6lbs
Other Features
Desktop or Wall Mount Socket (2holes)
3mm (0.13inch) marking on Temperature / Humidity Recording
Pen Position Adjustment Automatically，or with Switch
Standard Accessories
LR20，1.5V x 4
1 Pcs Chart Paper
1 Pcs Blue / Red Fiber Tip Pen
