Feed type: Pneumatic
Press stroke: 40 or 30 mm (1.57“ or 1.18“)
Cross section range: 0.08 – 6 mm ² (28 – 9 AWG)
Crimp height adjustment (wire & insulation): Increment: 0.025 mm (0.001”) Max.: 2.0 mm
Terminal pitch range Max.: 40 mm
Terminal thickness: < 1.2mm (<0.047"))
Weight: 5.0kg
Feed System: Side Feed & Rear Feed
Important note: SEDEKE recommends that wire samples be submitted in cases where there is doubt as to the processing capabilities of a particular machine
