Loading weight: 1.5 KG
Winding inner diameter: 5–200 mm
Winding length or number of turns: Adjustable
Disc diameter: Standard 280 mm
Sorting stroke: Standard 100 mm
Winding speed: 1–8 turns/s
Binding speed: 0.6 s/time
Cable tie length: 120–190 mm
Tie twist circles: Adjustable
Cable tie bundle diameter: 18–45 mm
Inner diameter of wire harness bundling: >50 mm
Cable tie specification: Iron core cable tie thickness <1 mm × width 3 mm
Input voltage: AC 220V 50 Hz/60 Hz
Rated power: 500 W
Weight: 50 KG
Dimensions: L1100 × W440 × H430 (without cable tie bracket)
