Schwarzbeck BBV 9721 Microwave Broadband Preamplifier (18 – 40 GHz)

Nominal frequency range: 18 – 40 GHz

Connectors: 50 Ω 2.92

Tube diameter: 22 mm

Gain: typ. 35 dB ± 4 dB

Gain min.: 27 dB

SWR typ.: < 2.6

Max. input power: –20 dBm (87 dBµV)

1 dB compression (at output): > +15 dBm (122 dBµV)

Noise figure: 5.5 dB

DC Power Supply 1: +8 V / 400 mA

DC Power Supply 2: –8 V / 50 mA

Power supply via female safety banana jacks: 4 mm

Dimensions: 370 × 95 × 65 mm

Weight: 0.86 kg
