Schurter DKLP-0329-0330 Current Compensated Choke DKLP Compensat choke 3A <60mH
ManufacturerSchurter(View more products from this manufacturer)
ModelDKLP-0329-0330
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 48 mm
Height: 30.8 mm
Length: 48 mm
Tolerance: - 30 %, + 50 %
Inductance: 30 mH
Unit Weight: 146 g
Mounting Style: Chassis Mount
Termination Style: Wire
Maximum DC Current: 3 A
Number of Channels: 1 Channel
Maximum DC Resistance: 130 mOhms
Self Resonant Frequency: 130 kHz
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 25 C
