Screen: LCD
Power supply: 90-450VAC 45/65Hz, 100-300VDC
Communication: Modbus RS-485
I/O output: 4DI, 2DO
Applications: Power management, Harmonic monitoring, ACB and MCCB monitoring and control
Measurement and display: Ampere, Voltage, Watt, Watt-hour, VAR, VAR-hour, VA, VA-hour, Hz, Power Factor
Setting current: 5A/1A
Dimensions (WxHxD): 96x72x96mm
Weight: 0.43kg
Sampling rate: 32 samples/cycle
Operating temperature: -25~70°C
Storage temperature: -40~85°C
Protection rating: IP52/IP30
