SCHNEIDER ATV310HU40N4E Inverter

Input voltage: 3 Phase 380-460VAC

Output voltage: 3 Phase 380-460VAC

Power: 4kW

Input current: 13.7A

Output current: 9.5A,

Max output frequency: 400Hz

EMC Filtering: No

Digital inputs: 4

Analog input: 1

Pulse input: No

Transistor output: 1

Relay output: 1

Analog output: 1

Control method/Control mode: Sensorless vector control, V/f Control

Connect to PC: RS485

Communication: Modbus RTU

Function: Ground fault, Option fault, Output phase loss, Output phase open, Over current, Over temperature, Overload, Overvoltage Protection, phase loss protection, Under voltage

Overload capacity at normal load (60s): 110%

Overload capacity at heavy load (60s): 150%

Brake kit: Integrated

Applications: Pottery machines, Machine tools, Material handling, Packaging machines, Printing machines, textile machines, Woodworking machines

Integrated cooling fan: Yes

Weight: 1.8kg

Dimensions: 140x184x151mm
