Application:
It is applicable for wide range of material for tension, compression, bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and components testing.
It is widely used in the corresponding industries, research and development, test institutes and training centers etc.
Standard:
ASTM, ISO, DIN, GB and other international standards.
Main Technical Parameters:
Max. Load: 20KN
Structure: Double Column Double Spaces
Control Method: Computer Control
Load Accuracy: 1 Class
Load Range: 2%~100% FS
Displacement Resolution: 0.01mm
Test Speed: 0.05~500mm/min
Tensile Space: 600mm (Can be customized)
Compression Space: 600mm (Can be customized)
Power Supply: AC220V±10%, 50Hz (Can be customized)
Grips: Wedge Type, Plate Type And Other Grips As Customers’ Demand
Dimension: 686*525*1880mm
Weight: 350.00 KG
