Samtec ERF8-060-07.0-L-DV-EGP-K-TR Sockets 0.80 mm Edge Rate(R) Rugged High Speed Socket
ManufacturerSamtec(View more products from this manufacturer)
ModelERF8-060-07.0-L-DV-EGP-K-TR
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Pitch: 0.8 mm (0.031 in)
Stack Height: 9 mm, 10 mm, 12 mm, 15 mm, 16 mm
Mounting Angle: Vertical
Mounting Style: SMD/SMT
Number of Rows: 2 Row
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Liquid Crystal Polymer (LCP)
Maximum Data Rate: 56 Gbps
Termination Style: Solder
Flammability Rating: UL 94 V-0
Number of Positions: 120 Position
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
