SALUKI SPA-8P2-10P4-23000 Solid State Power Amplifier (8.2GHZ - 10.4GHz, 23000W)
ManufacturerSALUKI(View more products from this manufacturer)
ModelSPA-8P2-10P4-23000
Warranty12 months
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Frequency Range: 8.2GHZ - 10.4GHz
Output Power: 23000W
P3dB Output Power: 15000W (min.)
Input Power: 0dBm
Gain: 74dB
Gain Flatness: ± 2dB
Input VSWR: 1:5:1
Harmonics: -30dBc
Spurious: -60dBc
Impedance: 50 ohm
Pulse Rise Time: 0.5μs (max.)
Pulse Fall Time: 0.5μs (max.)
Pulse Width: 50μs (max.)
Input port: Type N (female)
Output port: WR90
Communication Interface: LAN
Power Supply: AC 380V±10%, 50/60Hz
Cooling Type: Air cooling
Operating Temperature: 0 ~ 50℃
Dimension: 965×1145×1865 mm
