Input Signals
Thermocouple: K, R, B, N, E, T, J, S, WRE5-26, WRE3-25
Thermal resistance: pt1000, pt100, cu50
Number of Channels: 1-200
Power Consumption: ≤ 25 VA
Storage Interval: Self-setting from 1s to 19999s
Internal Memory: 70MB, or optional 2GB
Acquisition Mode: Cyclic
Alarm: Upper & Uppermost & Lower & Lowermost limit, 4 alarms per channel
Relay: 8-channel NO&NC relay 250VAC 5A
Power Supply: AC 85V-265V, DC 12V-25V
Distribution Output: 1-channel 24VDC (optional multi-channel 24V or 5VDC output)
Communication: Standard Ethernet, RS485, RS232 (optional USB/4G/WIFI wireless)
Standard Modbus TCP/RTU protocol
Temperature: Operating: -20°C to +50°C
Humidity: Operating: 0 – 90% RH
Dimension: 288 × 288 × 200 mm
