Roxer CROWN CLAMP [TM4] Crown Clamp (Ø 2.20 to 7.50 mm)

Standard clamp :

• Ø 2.20 to 7.50 mm

• Depth 0.80 mm, 1.40 mm

(2.00 mm only for Ø 7.00 mm)

Large format clamp :

• Ø 7.50 to 13.00 mm

• Depth and diameter tailored to your crown

Extra large format clamp :

• Ø 13.00 to 18.00 mm

• Depth and diameter tailored to your crown

Clamp with crown support :

• 3 available formats :

o Standard Ø 2.20 to 7.50 mm

o Large format Ø 7,50 to 13,00 mm

o Very large format Ø 13.00mm to 18.00 mm

• Depth 0.80 mm, 1.40 mm

(2.00 mm only for Ø 7.00 mm)

• Plastic crown support (fixed, depending on crown)

Clamp with crown support and spring stop :

• Tailored to your crown

• 3 available formats :

o Standard Ø 2.20 to 7.50 mm

o Large format Ø 7.50 to 13.00 mm

o Very large format Ø 13.00mm to 18.00 mm

Datasheet
