ROHM Semiconductor BH15LB1WHFV-TR LDO Voltage Regulators Std CMOS 1.5V Out 150mA

Width: 1.2 mm

Height: 0.6 mm

Length: 1.6 mm

Polarity: Positive

Output Type: Fixed

Mounting Style: SMD/SMT

Output Current: 150 mA

Output Voltage: 1.5 V

Line Regulation: 20 mV

Load Regulation: 10 mV

Number of Outputs: 1 Output

Input Voltage - Max: 5.5 V

Input Voltage - Min: 2.5 V

Dropout Voltage - Max: 450 mV

Pd - Power Dissipation: 410 mW

Ib - Input Bias Current: 40 uA

Voltage Regulation Accuracy: 1 %

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
