RIGOL MHO2024 Digital oscilloscope (4CH; 200 MHz)

Bandwidth: 200 MHz

Rise time: 2 ns

Analog channels: 4

Digital channels: 16(Probe opt.)

Memory depth: 500 Mpts (half-channel); 250 Mpts (full-channel)

Sample rate: 2GS/s per channel

Waveform capture rate: 1000000 wfms/s

Vertical resolution: 12 bits; 16 bits (high resolution mode)

Vertical scale: 100 μV/div - 10 V/div

Horizontal scale: 2 ns/div - 500 s/div

Interfaces: USB, LAN, HDMI, Trigger Out, Pass/Fail

Decoding options: USB host, USB Device, I2C, SPI, UART/RS232, CAN

Display: 10.1" LCD (1280 x 800)

Dimensions: 355 x 235 x 154 mm

Weight: 5.3 kg
