RIGOL DNA6084 Vector Network Analyzer (5 kHz – 8.5 GHz; 4 ports)

Bandwidth: 5 kHz – 8.5 GHz

Ports: 4

RF Connector: N-type (F)

IF bandwidth: 1 Hz – 10 MHz

Frequency resolution: 1 Hz

Amplitude resolution: 0.01 dB

Dynamic range (typ.): 127 dB (10 MHz – 6.5 GHz, at 10 Hz IF BW)

Noise floor: -125 dBm (10 MHz – 6.5 GHz, norm. to 1 Hz)

Max. input level: +27 dBm / ±35 VDC

Interfaces: LAN (GbE), USB 3.0 Host, USB 3.0 Device, HDMI, GPIB, Application I/O

Internal storage: 256 GB

Display: 10.1" capacitive touch (1280 × 800)

Dimensions: 358.1 x 214.8 x 300 mm
