Size: ∅ 0.9375” x 2.92”
Weight (with AAA alkaline battery): 3.5oz (100g)
Mounting Threads: ¼” – 20 (see website for optional accessories)
Operating Frequency: 512Hz
Frequency Tolerance: ± 30-50ppm (.00005 Hz)
Current Draw Tolerance: ± .015A
Recommended Battery: Duracell MX 2400 AAA cells (M3 Ultra) have the highest average Amp-Hours output.
Operating Range of battery is -4°F to 130°F.
Battery Life with Duracell M3 Ultra: 3.5 hours at 70°F
Typical maximum detection range with NaviTrack receiver (varies with ambient noise and interference):
+ In air: 25 ft
+ In cast iron: 15ft
Typical interference sources: Ductile iron, cast iron, wet salt laden ground.
