Renesas Electronics R7FA6M5BH2CBG#AC0 MCUs MCU RA6 ARM CM33 200MHZ 2M/512K BGA176

Core: ARM Cortex M33

Data RAM Size: 512 kB

Data RAM Type: SRAM

ADC Resolution: 2 x 12 bit

DAC Resolution: 2 x 12 bit

Data Bus Width: 32 bit

Interface Type: CAN FD, Ethernet, I2C, OSPI, QSPI, SCI, SDHI, SPI, SSIE, USB 2.0

Mounting Style: SMD/SMT

Number of I/Os: 132 I/O

Watchdog Timers: Watchdog Timer

Processor Series: RA6M5

Moisture Sensitive: Yes

Program Memory Size: 2 MB

Program Memory Type: Flash

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 2.7 V

Number of ADC Channels: 29 Channel

Maximum Clock Frequency: 200 MHz

Operating Supply Voltage: 2.7 V to 3.6 V

Number of Timers/Counters: 16 Timer

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
