Renesas Electronics 72V205L15TFGI FIFO 72V205 3.3V 256 X 18 SYNC

Access Time: 10 ns

Memory Size: 4.608 kbit

Timing Type: Synchronous

Organization: 256 x 18

Bus Direction: Unidirectional

Data Bus Width: 18 bit

Mounting Style: SMD/SMT

Moisture Sensitive: Yes

Number of Circuits: 1 Circuit

Supply Current - Max: 30 mA

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 3 V

Maximum Clock Frequency: 66.7 MHz

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
