Rek RK9800N Power meter (600V, 20A, 12kW)

Wiring method: AC

Display: LED digital screen with four windows displays V, A, W, PF, Hz, KW/h

Measurement items: Voltage V, current A, active power W, power factor PF, frequency Hz, electric energy KW/hVoltage V, current A, active power W, power factor PF, frequency Hz

Input voltage: 0～600V

Input current: 0～4A / 3.5～20A

Power (P): 12KW

Power factor (PF): ﹣1.000～+1.000

Test frequency: 45Hz ～ 65Hz (refers to the frequency that the tester can detect)

Electric energy accumulation range: 0～1000KW/h

Basic accuracy

Voltage/Current: ± (0.4% reading + 0.1% range)

Resolution

Voltage: 0.1V

Current:

1mA (current less than 10A)

10mA (current greater than 9.999A)

Alarm function: None

Communication function: RS232 (DB9) interface (optional)

Measurement speed: 2 times / second

Lock function: Used when data fluctuates, convenient for reading

Working power: ≤AC 220V ±20%, 50/60Hz

Power consumption: <8W (220V, 50Hz)

Dimensions (DxWxH): 275*242*128mm

Weight: 2.8kg

Standard: PC software (download from official website), power cord

Optional: RS232 communication cable RK00002
