Rek RK9110A Program Hipot tester (AC:0.001mA-10mA, DC:0.1uA-5mA)

Pressure test

Output voltage (KV): AC: 0.05-5.00 DC: 0.05-6.00

Test accuracy: ±(2.0% setting +2V)

output precision: ±(2.0% setting +5V) no load

Test current (mA): AC: 0.001mA-10mA DC: 0.1uA-5mA

Test accuracy/ Setting error: ±(2.0% reading + 5 digits)

Arc Detection

Current measurement range: 1mA-20mA

testing time: 0.1S-999.9S

Output frequency: 50Hz/60Hz

Input characteristics: 115V/230V±10% 50Hz/60Hz

test alarm: Buzzer, LCD display, FAIL indicator

keyboard lock: Independent keyboard lock key

screen size: 5 inch TFT LCD

Communication Interface: HANDLER, RS232, RS485, USBDRV (computer interface), USBHOST (U disk interface)

Voltage rise time: 0.1S-999.9S

Test time setting (AC/DC): 0.2S-999.9S

Voltage fall time: 0.1S-999.9S

waiting time: 0.2S-999.9S

storage: 16M flash, each file can store 50 test steps

weight: 14KG

Standard accessories: Test clip, ground clip, cross uncontrolled high voltage rod, power cord, RS232 serial port cable

Optional accessories (complete set):16G U disk (including PC software), RS232 to USB cable, USB to square port cable, RK00031, RK101 series check box
