Rek RK2512N+ Low Resistance Tester (1μΩ-2MΩ)

Test Range: 1μΩ-2MΩ

Test Accuracy: 0.05% (The Minimum Resolution) 10μΩ

Test Current: 1A 100mA 10mA 1mA 100μA 10μA 1μA

Display Mode: Four And A Half Digit Display: 00000-19999

The Voltage Of Open Circuit: <5.5V

Range Mode: Manual/Automatic

Test Speed: Fast 15 T/S Slow 8 T/S

Sorting: Onlap,Qualified,Downlap

Trigger: Internal Trigger,Manual Trigger,External Trigger

Interface: Interface Of RS-232C Interface Of Handler(PLC)

Work Environment: 0℃～40℃,≤85% RH

Exterior Dimension: 330×270×110mm

Weight: 4kg

Accessory: Test Line,Power Line
