Rational CMS-8105M Manual Coordinate Measuring System (X: 800 Y: 100 Z: 600mm)

Travel (mm)

X: 800

Y: 100

Z: 600

Accuracy:

Space accuracy: MPEE= (3.5+L/250)μm 　　　　　　　　　　

Monaxial accuracy: MPEE1= (3.0+L/250)μm

Differentiate force：0.5μm

Construction: Sliding bridge

Total power: 50W(excluding PC)

System characteristics:

Probing system: NENISHAW WH20i/ Video probing system

Measuring software ：RationalDMIS (manual)/ QMS3D-M

Dimension (m): 1.65×2.1×2.85

Weight: 2460kg

Max. load-bearing: 1000kg

Packing dimension (m): 1.9×2.5×2.4

Power supply：AC 100-240V 50/60Hz

Temperature range: 20±2℃ <1℃/h <℃/24h <1℃/m

Air flow：120L/min（0.4MPa）

Bleed pressure: 0.5MPa. Humidity: 40%—70%

Product brief:

Manual Coordinate Measuring Machine is a high precision instrument integrating optics, machinery, electronics and computing. It is convenient to measure coordinate point, profile and Dimension, and form and location tolerance.

It is mainly used in the field of machinery, electronics, instrument, meter, watch, light industry, plastics as well as measuring chambers, laboratories of institutes and universities, research institutes, metrological verification departments and workshops, etc.
