Metrological parameters
Maximum capacity [Max]: 50 g
Readability [d]: 0.1 mg
Tare range: -50 g
Adjustment: external
Maximum sample weight: 50 g
Heating module: IR emitter
Moisture content repeatability: +/-0.05% (sample ~ 2g), +/-0.01% (sample ~ 10g)
Moisture content readability: 0.0001%
Drying temperature range: Max 160 °C
Physical parameters
Leveling system: manual
Display: LCD (backlit)
Maximum sample height: 20 mm
Weighing pan dimensions: ø90, h= 8 mm
Net weight: 4.8 kg
Gross weight: 6 kg
Protection class: IP 43
Features of use
Display mode: %MC, %DC, %ATRO MC, %ATRO DC, g, g/kg MC, g/kg DC, -%MC
Drying method: 4 drying profiles (standard, fast, step, mild)
Finish mode: 4 modes (automatic, manual, time-defined, user-defined)
Additional functions: sample traceability
Communication interface
Communication interface: RS232¹, USB-A, USB-B, Wi-Fi®
Electrical parameters:
Power supply: 200V-240V AC 50/60Hz
Power consumption: 6 W
Heating module power: 450 W
Environmental conditions
Operating temperature: +10 — +40 °C
SOP – metrological tests
Mass indication control: External mass standard 50 g, 100 g, 200 g (depending on the type of moisture analyzer)
Internal adjustment: For .IC models only, GLP report
External adjustment: For all models, GLP report
Drying temperature control: One- or two-point, depending on the drying profile (equipment: GT105k-12/Z Control Thermometer)
Moisture content indication control: Certified MV Test Set
Adjustment
Internal / External adjustment: Depending on the type of moisture analyzer, GLP report
Drying temperature adjustment: Three-point adjustment at defined temperatures, programmable values (equipment: GT105k-12/Z Control Thermometer)
