Radiall R114313000W Connectors SMB / STRAIGHT BULKHEAD JACK FRONT MOUNT CRIMP TYPE - CABLE 2.6/50+75 S
ManufacturerRadiall(View more products from this manufacturer)
ModelR114313000W
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Gender: Jack (Pin)
Polarity: Reverse
Impedance: 50 Ohms
RF Series: RP-SMB
Cable Type: RG-174, 179, 316
Body Finish: Gold
Orientation: Straight
REACH - SVHC: Details
Body Material: Brass
Mounting Style: Bulkhead - Front Mount
Voltage Rating: 335 V
Contact Plating: Gold
Contact Material: Beryllium Copper
Maximum Frequency: 4 GHz
Termination Style: Crimp
Coupling Mechanism: Slide On
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 65 C
