PRESYS T-25NL Calibration Baths - for large calibration volume (-25 °C to 155 °C; ± 0.02 °C)

Operating Range (ambient temperature: 23 °C):-25 °C to 155 °C

Display Accuracy: ± 0.1 °C

Resolution: 0.01 °C

Stability: ± 0.02 °C

Axial Uniformity (40 mm):

0.06 °C (Dry Block)

0.025 °C (Stirred Liquid)

Radial Uniformity (homogeneity):

0.02 °C (Dry Block)

0.02 °C (Stirred Liquid)

Heating Time: 25 min (25 °C to 140 °C)

Cooling Time: 20 min (25 °C to -25 °C)

Environmental Operating Conditions:0 to 50 °C / 0 to 90% UR

Electric Power: 300W

Display: Graphic vacuum fluorescent with contrast adjustment

Well Diameter x Depth: Ø 35 mm x 160 mm

Dimension (HxWxD): 315 x 180 x 270 mm

Weight: 12 kg

Datasheet
