PMS ENODE Distributed I/O Controller

Application
-Environmental monitoring and control
+ Differential pressure, temperature, humidity, air velocity, and other sensor signals
+ Alarm lamp or traffic light control
+ Flashing modes
- Process monitoring and control
+ Doors and switches monitored at each stage of process
- Networked data-logging
- Remote data acquisition
Processor Unit
+ Operating system Windows® CE 3.0
+ Processor AMD Elan SC400, 32-bit, 66 MHz
+ Ethernet 10/100BaseT (RJ-45)
+ RAM 64 MB
+ Non-volatile storage 32 MB
+ Serial ports One, RS-232 (Up to 115 K Baud)
+ Power 5 VDC @ 1 A max.
+ Dimensions (l, w, h) 4.6 x 3.4 x 6 in (11.6 x 8.5 x 15.0 cm)
Power Module
+ Input connector 90 – 260 VAC, 50-60 Hz IDE
+ Output 5 V, 10 A max.
Analog Input Module
+ Inputs 16 single-ended, 8 differential
+ Resolution 12-bits (1 in 4096)
+ Input ranges 0 – 10 V or 0 – 20 mA
+ Over voltage protection Power on or off, - 40 V to + 55 V
+ Overall accuracy ± 0.25% full scale
+ Dimensions (l, w, h) 4.6 x 1.7 x 6 in (11.6 x 4.2 x 15.0 cm)
Digital Input Module
+ Digital input Opto isolators 16 inputs
+ Turn-on time 6 msec min.
+ Turn-off time 35 msec max.
+ Isolation Channel to channel 500V
+ IsolationInput to output 1500V
Current consumption 5 VDC 500 mA max.
Dimensions (l, w, h) 4.6 x 1.7 x 6 in (11.6 x 4.2 x 15.0 cm)
