Pintech PT-8020 Differential probe (70MHz, 14kVp-p)
ManufacturerPintech(View more products from this manufacturer)
ModelPT-8020
USD 1,410.00
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Bandwidth(-3dB): DC-70MHz
Attenuation Ratio: 100X, 1000X
Rise time: 5ns
Accuracy: ±2%
Testing Vp-p: 1400V-14kV
Input DC Voltage: 700V-7kV
AC rms: 4900V
Impedance: 20MΩ//0.5pF
Oscilloscope input impedance: 1MΩ
Power: 6V adapter
CMRR (Typical): 50Hz＞80dB；20kHz＞60dB
Working Temperature: 0~50℃
Working Humidity: 20~75%RH
Weight: 415g
Dimension (LxWxH): 187x83x41mm
