Pintech PT-2720 AC&DC current probes (300kHz,0.4-200Ap-p)
ManufacturerPintech(View more products from this manufacturer)
ModelPT-2720
USD 681.60
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Measuring range: 0.4~10Ap-p; 10A~200Ap-p
RMS: 70A
Conversion ratio: 50mV/A(20X); 5mV/A(200X)
Bandwidth(-3dB): DC-300kHz
Accuracy: 2%
Rise time: 1.2μs
Working Voltage: 600V
Battery: 9V alkaline battery
Low battery Indicate: with green LED light when >6.5V
Overload indicator: Red LED light indicates the over measuring current, change the range
Clamp.Dia.: Diameter 11mm
Working Temperature and Humidity:0~﹢50℃; 20~75%RH
Cable length: 2m
Size: 231x36x67 mm
Weight: 330g
