Pintech PA30032 DC regulated power supply (0-300V, 0-32A)

DC Output:

Voltage: 0-300V

Current: 0-32A

Working: Switch PWM

INPUT:

Phase: 3Φ 4W

Voltage: 380V±10%

Frequency: 50Hz±10%

Ripple: 1% FS (full scale) voltage

Power Regulation: ±0.5%FS

Load Regulation: ±1%FS

Voltage Resolution: 0＜1000:0.1V； V0≥1000V：1V

Current Resolution: Output 100A>I0≥10A: resolution 0.01A; output 1000A>I0≥100A: resolution 0.1A

Power Resolution: 0.1W

LED Display: voltage V, current A, power W, time T

Memory: A total of 9 groups, each group can remember the voltage and current values, which can be quickly and easily called

Protection: overvoltage, overcurrent, overtemperature, short circuit

Environment: 0-40℃ 20-80% (non-condensing)

Weight: 50KG

Size WXHXD (mm): 430*360*550
