Pintech DP-25 Differential probe (25MHz, 1400Vp-p)
ManufacturerPintech(View more products from this manufacturer)
ModelDP-25
USD 294.00
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Bandwidth(-3dB): DC-25MHz
Rise time: 14ns
Attenuation Ratio: 20X,50X,200X
Accuracy: ±2% (20 minutes after the warm-up)
Testing Vp-p: 140V-350V-1400V
Input DC Voltage: 70V-175V-700V
AC rms: 500Vrms
Tiếng ồn: ≤2.0mV rms
CMRR (Typical): 60Hz:＞80dB；100Hz:＞60dB;1MHz:＞50dB
Input impedance: 4MΩ//1.2pF
Oscilloscope input impedance: 1MΩ
Power: 9V adapter
Max. consumption: 35mA
Temperature and Humidity: 0~50℃ and 10~85%RH
Dimension (LxWxH) mm: 195x55x30
Weight: 250g
