Pintech APA5120A Programmable AC power supply (20kVA, 168A, 1φ2W)

Power: 20kVA

Out Frequency: 45~200Hz(40-500)，0.01 Step

Max Current: L=120V 168A; H=240V 84A

Phase: 1φ2W

Current Resolution: 0.1A

weight(kg): 150

volume WxHxD (mm): 430*700*550

Common characteristics:

INPUT:

Phase: 3φ4W

Voltage: 380V±10%

Frequency: 47Hz~63Hz

Output Voltage: low grade 0-150V AC / high grade 0-300V AC AUTO

Line regulation: 0.1%

Frequency regulation: 0.01%

Waveform distortion T.H.D: 2% (Pure resistive load)

Display: Voltage Vrms、Current Arms、Frequency Fre、Power Wattage、Power factor PF

Number of Storage Groups (Memory): M1 (V_F_A), M2(V_F_A)... M9(V_F_A)

Set the current limit: O-Max Current
