PHYWE ADA-LPB-423I Precision Balance (420g : 0.001g)

FEATURES:

• External menu-driven calibration allowing user-selectable range of calibration weights.

• Internal calibration (option) for outstanding accuracy without the need for manual calibration.

• Mains powered.

• Wipe clean ABS plastic housing with 304 grade stainless steel pan.

• Large easy to read dual line LCD display with backlight.

• Standard applications include weighing, percentage weighing, parts counting, dynamic (animal) weighing and solid and liquid density determination.

• Bi-directional RS-232 interface and USB interface as standard.

• Can be configured to print a GLP Compliant report after each calibration to include the time, date, balance number and a verification of the calibration.

• Force-restoration mechanism for supreme accuracy, or alloy load cell technology for stable yet accurate weighing.

• Automatic temperature compensation.

• Multiple weighing units.

• Easy to use, wipe-clean sealed membrane keypad.

• Below balance weighing facility (accessory hook required).

• Display in a choice of 4 languages – English, German, French & Spanish.

• Password protection.

• Security locking point.

Specifications:

Maximum Capacity: 420 g

Readability (d): 0.001 g

Min. weight (USP): 4 g

Repeatability: (Std. Dev) 0.002 g

Linearity: 0.003 g

Units of Measure: Kilograms, grams, milligrams, carats, grains, Newtons, pounds, ounces, troy ounces, Drams, Taels-HK, Taels-T, Taels-S, Mommes, Tolas, Ticals,pennyweight, custom

Stabilization Time: Typically 3 seconds

Operating Temp: 15ºC to 35ºC recommended, 40 – 60 % RH (non-condensing)

Power Supply: External mains power adapter - supplied as standard (Input Voltage 100–240 VAC, 50/60 Hz)

Input Voltage: 18 VDC - 830 mA

Display: LCD with black backlight, 7 characters, 24 mm high, and symbols

Draft Shield (w x d x h): Sliding door Draft Shield (198 x 212 x 240 mm)

Pan Size: Round, 80mm diameter

Overall: Dimensions (wxdxh): 228x377x333 mm (9x14.8x13.1 in)

Net Weight: 4.9 kg / 10 lb 12.8 oz

Calibration Suffix i = internal calibration mechanism, e = external calibration only
