PHYWE 13542-93 Power Supply (0~20 VDC, 0~25 VAC)

Function and Applications

Standard heavy-duty power supply unit for low voltage. Supplies continously adjustable DC and AC voltages & 2 frequently requiredfixed voltages.

Equipment and Technical Data

AC output: ca. 0.2...25 V/12 A

DC output: ca.0.2...20 V/12 A

Max. current (short-term): 13 A

Additional fixed voltages: 6 V AC/6 A12 V AC/6 A

Max. current (short-term): 10 A

Max. power: 375 VA

Fuses: one 13 A and two 10 A

Displays: 2 digital meters for current and voltage

Supply voltage: 230 V AC

Dimensions (mm): 230 x 236 x 234

Manual
