PEGO LSG6K10D Ring Wave and Lightning Surge Generator (2 in 1) (100kHz±10%, 6kV (Max) ±5%)

Parameters of Ring Wave Generator:

Voltage Oscillation frequency (open): 100kHz±10%

Output voltage(open): 250V~4000V）±10%

Frontier(open circuit voltage,T1,10%~90%): 0.5μs±30%

Frontier(short circuit voltage,T2,10%~90%): ≤0.9μs

Decay Rate (open circuit voltage)

40%<（PK2）/（PK1）<110%

40%<（PK3）/（PK2）<80%

40%<（PK4）/（PK3）<80%

Short circuit current at 3500V(PK1):

292A±10% @12Ω

117A±10%@30Ω

Interval: 1s~99s

Impulse times: 1~9999times

Output mode: Positive, negative, positive/negative auto

Output Impedance: 12Ω，30Ω

Phrase: asynchronous, synchronous

Coupling and decoupling network(CDN): 16A single Phase or 20A 3 phases / 5wires

Parameters of Surge Generator

Output voltage (open): 6kV (Max) ±5%

Front time: 1.2μs ±30%

Time to half-value: 50μs ±20%

Output current (short): 3kA (Max) ±5%

Time to half-value: 20μs ±20%

Output polarity: Positive, negative, positive/negative automatically

Output impedance: 2Ω±10%

Synchronization,asynchronization: Synchronization,asynchronization

Inject phase: Freely set at 0－360°，resolution:1°

Trigger mode: Auto or manual, single

Surge times: 1-9999 times

Memories: 1000 groups

Surge interval: 20-9999s

Accuracy:: 5％

CDN

AC：single phase 300V，10A (16AMax), 50/60Hz

DC: 300V, 10A (Max)

Working environment

Temperature:15°C－35°C humidity:0%－75%

EUT power supply: AC220±10%, 50/60Hz, about 300W

Dimension: W470mmxH260mmxD500mm

Weight: About 35kg

This equipment is a 2 in 1 equipment, which combinates the ring wave generator and lightning surge generator. The equipment can meet the test requirements of IEC61000-4-5 and IEC61000-4-12.
