Peak Instruments X-8200 Xenon Spectrophotometer (2nm)

Display: 7 inch TFT

Keyboard Control: Silicone Buttons

Optical System: -Double Beam

-Holographic grating, 1200 lines/mm

Slit Width: 2nm

Wavelength Range: 190 - 1100nm

Wavelength Accuracy: ±0.6nm

Wavelength Repeatability: ≤0.2nm

Photometric Accuracy: 0.3%T (0-100%T), ±0.005A(0-0.5A), ±0.01A(0.5-1A)

Photometric Repeatability: ≤0.2%T (0-100%T), 0.003A(0-0.5A), 0.005A(0.5-1A)

Stray Light: ≤0.1%T@220nm,360nm

Stability: ±0.002A/h@500nm

Photometric Range: 0-200%T, -0.3-3.0A, 0-9999C(0-9999F)

Baseline Flatness: ±0.002A(200-1000nm)

Noise: 0.002A@500nm

Working Mode: T,A,C,E

Wavelength Setting: Automatic

Scanning Speed: High, Medium and Low.

Detector: Solid Silicon Photodiode

Light Source: Xenon Lamp

Data Output: RS232C Serial, USB Drive, USB HOST

Processor: Cortex_M3, 120Mhz

Power Requirements: AC 110-220V 50-60Hz

Shipping Dimensions & Weight: 790*660*370mm, 29kg
