Peak Instruments C-7000V Visible Spectrophotometer (320 ~ 1100nm)

Display:7-inch color LCD screen.

Wavelength Range: 320 - 1100nm

Slit Width: 2nm

Wavelength Accuracy: ±0.3nm

Wavelength Repeatability: ≤0.2nm

Photometric Accuracy: 0.3%T (0-100%T) , ±0.002A(0-0.5A) , ±0.004A(0.5-1A)

Photometric Accuracy: ≤0.15%T (0-100%T), 0.001A(0-0.5A), 0.002A(0.5-1A)

Stray Light: ≤0.05%T@220nm,360nm

Stability: ±0.002A/h@500nm

Baseline Flatness:±0.002A

Noise: ±0.0005A

Working Mode: T, A, C, E

Wavelength Setting: Automatic

Photometric Range: 0-200%T, -0.3 - 3A, 0-9999C(9999F)

Detector: Solid Silicon Photodiode

Software: Optional with scanning function

Printer: Optional

Keypad: Silicone buttons

Data Port: USB

Light Source: Tungsten Halogen Lamp

Power requirements: AC110-220V 50-60Hz

Humidity Range: Less than 85%

Shipping Dimensions & Weight:730*610*390mm, 21kg
