PCE USC 20 Condition Monitoring Ultrasonic Thickness Gauge (0.5~9999 mm)

Specifications

Measurement range:0.5 ... 9999 mm (longitudinal shaft steel), continuously adjustable

Sound velocity:1000 ... 15000 m/s, continuously adjustable, coarse adjustment

Display delay:-10 ... 2000 mm

Probe delay:0.00 ... 199.9 µs

Transmitting impulse:400 V negative signal peaks

Damping (impulse generator):50 / 100 / 200 / 500

Work mode:One- or two-probe measurement

Operating frequency range:0.5 ... 20 MHz

Pulse repetition frequency:40 / 250 /1000 Hz optional

Amplification / gain (receiver):0 ... 110 dB

Rectification (receiver):Whole wave, positive half wave, negative half wave, high frequency representation

Alarm limits:Limit A (Gate A) and Limit B (Gate B),

Adjustable as positive or negative peak with automatic (visual or audible) alarm

Measurement mode:Limit value / Extreme value mode

Measurement deviation horizontal linearity:≤0.1 %

Measurement deviation vertical linearity:≤3 %

Excess sensitivity:≥62 dB

Dynamic range:≥40 dB

Resolution remote field:≥30 dB

Sampling rate:400 MHz

Measurement data storage:500 records

Signal reproduction:Permanent recording of signals with the playback of dynamic echoes

Surface adjustment:Automatic adjustment of the error position of the angled probes

Automatic amplification:20 ... 80 %, in 1 % steps

Menu language:English, Chinese

Interface:USB-A, USB-B, Ethernet

Display:5.7 " TFT color LCD (640 x 480 pixels)

Operating temperature:-10 ... +50 °C

Power supply:AC: 100 ... 240 V

DC: 15 V / 4 A

BatteryLi-ion battery: (10.8 V, 5200 mAh)

Battery opearting time per charge:>6 hours

Protection class:IP54

Weight:1.4 kg (incl. battery)

Dilivery Contents

1 x PCE-USC 20 condition monitoring ultrasonic thickness gauge

1 x Li-ion battery

1 x charging adapter

2 x probe cables (1.8 m long)

1 x USB cable

1 x USB flash drive with software

1 x carrying bag with strap

1 x carrying case

1 x contact transducer probe (90 °)

1 x contact transducer probe (70 °)

1 x contact transducer probe (60 °)

1 x contact transducer probe (45 °)

1 x calibration certificate

1 x user manual
