PCE-C-R12LFC-H4 Force Sensor (5~50 kg)

Manufacturer: PCE-ANH

Model : PCE-C-R12LFC-H4

Warranty : 12 months

Specification

Rated load / force F.S.:

5 / 10 / 20 / 30 / 50 kg

50 / 100 / 200 / 300 / 500 N

! Rated load / force selectable !

Limit load / force:120 %

Breaking load / force:150 %

Rated output:1.0 – 1.5 mV/V

Operating range of supply voltage:2.5 V – 5 V

Maximum supply voltage:5 V

Deviations of the zero signal:± 2 % F.S.

Linearity deviation:0.5 % F.S.

Reverse voltage (hysteresis):0.5 % F.S.

Repeatability:0.5 % F.S.

Stress creep (30 min):0.1 % F.S.

Input resistance:350 ± 10 Ω

Output resistance:350 ± 3 Ω

Insulation resistance:≥5000 MΩ / 100 VDC

Nominal range of ambient temperature:-10 … 60 °C / 14 ... 140 °F

Service temperature range:-20 … 80 °C / -4 ... 176 °F

Temperature coefficient of characteristic value:0.1 % F.S. / 10 °C

Temperature coefficient of zero point:0.1 % F.S. / 10 °C

Sensor cable:Ø 2 x 3 m / (ends open)

Cable assignment:

EXC+ = red

EXC- = black

SIG+ = green

SIG- = white

GND = yellow

Material / measuring body:stainless steel

Protection:IP65
