PCE PCE-RVP 2200 Vacuum Gauge (15 Micron)

- General Technical Data:

Connection Type: 1/4" SAE, 3/8" SAE

Motor Power: 1.5 HP

Flow Rate: 340 l/min

Oil Capacity: 660 ml

Ultimate Vacuum: 15 Microns

Protection Class: IP20

Power Supply: Schuko Plug (230V AC)

Weight: 15.13 kg

Device Weight with Accessories: 15.2 kg

Device Weight with Accessories and Packaging: 16.6 kg

Dimensions (L x W x H): 390 x 140 x 260 mm

Operating Conditions: 5 ... 40 °C, 20 ... 80 % r.F.

Storage Conditions: 5 ... 40 °C, 20 ... 80 % r.F.

- Delivery Scope:

1 x Vacuum Gauge PCE-RVP 2200

2 x 300 ml bottle

1 x User Manual
