Particles Plus UM-27000 Rotary Vane Vacuum / Pressure Pump

Voltage (V): 6 / 4.5 / 3

Current (mA) Min / Max:

• 6 V: 290 – 500

• 4.5 V: 200 – 330

• 3 V: 110 – 180

Flow (LPM):

• 6 V: 5.5

• 4.5 V: 4.3

• 3 V: 3

Vacuum (mBar):

• 6 V: 125

• 4.5 V: 95

• 3 V: 45

Sound Level (dB):

• 6 V: 60

• 4.5 V: 59

• 3 V: 55

External Surface: Stainless steel

Dimensions (L x W): 2.25″ x 1.2″ (5.6 x 3.0 cm)

Weight: 0.22 lb (0.1 kg)

Power: 6 VDC

Operating Temperature: 41º – 104ºF (5º – 40ºC) / 20% – 95% non-condensing

Storage Temperature: 32º – 122ºF (0º – 50ºC) / up to 98% non-condensing
