PANASONIC EEU-FS1A331B Aluminum Electrolytic Capacitors 10VDC 330uF 5000H 6.3x11.2mm
ManufacturerPANASONIC(View more products from this manufacturer)
ModelEEU-FS1A331B
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
ESR: 130 mOhms
Life: 5000 Hour
Length: 11.2 mm
Diameter: 6.3 mm
Tolerance: 20 %
Lead Style: Straight
Capacitance: 330 uF
Unit Weight: 650 mg
Lead Spacing: 5 mm
Ripple Current: 455 mA
Leakage Current: 33 uA
Termination Style: Radial
Voltage Rating DC: 10 VDC
Dissipation Factor DF: 0.19
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
