PANASONIC EEU-FR1C392L Low ESR Radial Leaded Aluminum Electrolytic Capacitor 16VDC 3900uF 12x35mm LS5mm
ManufacturerPANASONIC(View more products from this manufacturer)
ModelEEU-FR1C392L
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
ESR: 12 mOhms
Life: 10000 Hour
Length: 35 mm
Diameter: 12.5 mm
Tolerance: 20 %
Lead Style: Straight
Capacitance: 3900 uF
Unit Weight: 6.800 g
Lead Spacing: 5 mm
Ripple Current: 3.75 A
Termination Style: Radial
Voltage Rating DC: 16 VDC
Dissipation Factor DF: 0.22
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
