PANASONIC EEE-FT1A221AV High Temp Electrolytic Capacitors 10VDC 220uF 20% Anti-Vibe AEC-Q200
ManufacturerPANASONIC(View more products from this manufacturer)
ModelEEE-FT1A221AV
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
ESR: 260 mOhms
Life: 2000 Hour
Length: 6.1 mm
Diameter: 6.3 mm
Tolerance: 20 %
Capacitance: 220 uF
Qualification: AEC-Q200
Ripple Current: 300 mA
Termination Style: SMD/SMT
Voltage Rating DC: 10 VDC
Dissipation Factor DF: 0.19
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
