PANASONIC ECQ-E4183JF9 Metallized Polyester Film Capacitors 400VDC 0.018uF 5% MPET L/S=5mm
ManufacturerPANASONIC(View more products from this manufacturer)
ModelECQ-E4183JF9
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 4.4 mm (0.173 in)
Height: 12.5 mm (0.492 in)
Length: 10.3 mm (0.406 in)
Tolerance: 5 %
Dielectric: Polyester
Lead Style: Crimped
Capacitance: 0.018 uF
Unit Weight: 600 mg
Lead Spacing: 7.5 mm (0.295 in)
Lead Diameter: 0.6 mm
Number of Pins: 2 Pin
Capacitance - nF: 18 nF
Capacitance - pF: 18000 pF
Termination Style: Radial
Voltage Rating DC: 400 VDC
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
