Pacificpower 105AMXT Programmable Linear AC Power Source (500VA, 135/270L-N/L-L)

- Rated Power (VA): 500

- Output Form: 1Ø/2Ø

- Output Voltage Max (l-n/l-l):

Direct: 135/270

Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1): 202/404; 270/540; 338/600

- Output Current (Arms):

Direct: 4/2

Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1): 2.6/1.3; 2/1; 1.6/0.8

- Frequency Range:

Direct: 20~5000

Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1): 45~5000; 45~5000; 45~5000

- Input Power: 1Ø 47-63Hz

- Unit Height (In/mm/U): 5.25/133/3U

- Unit Weight (Lbs/Kg): 97/44

- Output Frequency Line Regulation: 0.1% max for a ±10% line change

- Load Regulation: Direct Coupled Ranges:

0.25% 20 to 2,000 Hz.

0.50% 2,000 to 5,000 Hz.

Improves to less than 0.05% with external sense and CSC enabled.

-Output Distortion

0.1% THDAVG 45 to 1,000 Hz

0.25% THDAVG 20 to 5,000 Hz

-Ripple and Noise: -72dB

- Response Time: 5 µsec typ. For step load change.

Small signal bandwidth = 5 Hz to 50 KHz
