OWON SPE8105 DC Power Supply (0 - 80V, 10A; 500 W)

Output Voltage: 0 - 80V

Output Current: 10A

Max Output Power: 500W

OVP: 85V

OCP: 11A

OTP: 85℃

Load Regulation: ≤20mV（Voltage）；≤10mA（Current）

Power Regulation: ≤20mV（Voltage）；≤10mA（Current）

Setting Resolution: 10mV / 1mA

Readback Resolution: 10mV / 1mA

Setting Accuracy（25℃±5℃）:

Voltage: ≤0.05% ± 20mV

Current: ≤0.05% ± 10mA

Readback Accurac（25℃±5℃）:

Voltage: ≤0.05% ± 20mV

Current: ≤0.05% ± 10mA

Ripple/Noise (*): ≤50mVp-p；≤15mAp-p

Output temperature coefficient （0℃-40℃）: 100ppm/℃（Voltage）；200ppm/℃（Current）

Readback temperature coefficient: 100ppm/℃（Voltage）；200ppm/℃（Current）

Response Time (50%-100% rated load): ≤5.0ms

Storage: 4 groups of data

Display: 2.8inch LCD (IPS)

Interface: USB Device

Dimension: 82mm（W）× 142mm（H）×226mm（D）

Weight: Approx. 1.8 kg
