Channel: 2
Frequency Output: 35MHz
Sample Rate: 125MSa/s
Vertical Resolution: 14 bits
Waveform
Standard Waveform: sine, square, pulse, ramp, and noise
Arbitrary Waveform: exponential rise, exponential fall, sin(x)/x, step wave, and others, total 150 built-in waveforms, and user-defined arbitrary waveform
Frequency
Sine: 1μHz - 35MHz
Square: 1μHz - 15MHz
Pulse: 1μHz - 15MHz
Ramp: 1μHz - 1MHz
Noise: 20MHz (-3dB，typical)
Arbitrary Waveform:1μHz -10MHz
Frequency Resolution: 1 μHz or 7 significant figures
Frequency Stability: ±30 ppm at 0±40℃
Frequency Aging Rate: ±30 ppm per year
Arbitrary
Waveform Length: 2 - 8K points
Sample Rate: 125Ma/s
Amplitude
into 50Ω Load: 1mVpp - 10Vpp（≤10MHz）; 1mVpp - 5Vpp （≤70MHz）
DC Offset Range (AD+DC): ±(10 Vpk – Amplitude Vpp/2) high resistance; ±(5 Vpk – Amplitude Vpp/2) 50 Ω
DC offset Resolution: 1mV or 4digits
Load Impedance: 50Ω (typical)
DC offset Accuracy: ±(1 % of |setting| + 1 mV + amplitude Vpp x 0.5%)
Modulation
Type: AM, FM, PM, FSK, sweep, Burst
Internal Modulation Frequency: 2 mHz to 100 kHz
Sweep
Carrier: Sine, rectangular wave, ramp wave, arbitrary wave(Except DC)
Minimum/Maximum Starting Frequency: 2mHz（minimum）/ maximum frequency of corresponding carrier
Minimum/Maximum Termination Frequency: 2mHz（minimum）/ maximum frequency of corresponding carrier
Trigger Source: internal, manual
Burst
Waveform: Sine wave, square wave, ramp wave, pulse wave and arbitrary wave (Except DC)
Types: N-Cycle
Trigger source: Internal, manual
Carrier frequency: 1μHz ≤ Offset ≤ Maximum frequency of corresponding carrier /2
Input / Output
Display: 3.6-inch TFT LCD with resolution 480 x 272
Communication Interface: USB Device
Mechanical specifications
Dimension (W×H×D): 200mm x 68.5mm x 74.5mm
Weight (without package): 0.5kg
