OscarMax S755 NC Die Sinker Electrical Discharge Machine (1630 x 950 mm, 10KVA)

Table Travel (X DM/SM): 700 mm

Table Travel (Y): 550 mm

Servo Travel (Z): 250 mm

Servo Travel (Z2): 300 mm

Max. Workpiece Dimensions (WxD): 1630 x 950 mm

Max. Filling Height of Dielectric Tank: 385 mm

Distance Between Chuck to Table: 190 - 740 mm

Max. Workpiece Weight: 2000 kg

Max. Electrode Weight: 250 kg

Table Size (WxD): 1100 x 600 mm

Machine Weight: 3100 kg

Generator

Max. Working Current:90A

Overall Power Consumption:10KVA

Weight: 350kg

Dielectric

Tank Capacity:1120 L

Filter Density:20μm

Filter Elements: 4 pcs

Datasheet
