Optika B-510POL Trinocular polarizing microscope (IOS W-PLAN POL 40x/0.65)

Observation mode: Brightfield, transmitted polarized light and conoscopy.

Bertrand lens and polarizing attachment: Swing-out type with centering mechanism for observation in conoscopy/orthoscopy. Rotatable analyzer from 0° to 90° with graduated scale.

Tint plates: 1° order red (λ); λ/4; Quartz wedge.

Head: Trinocular (fixed 50/50), 30° inclined, 360° rotating.

Interpupillary distance: Adjustable between 50 and 75 mm.

Dioptric adjustment: On the left eyepiece tube.

Eyepieces: WF10x/22 mm, high eye-point and with rubber cups. One with crosshair.

Nosepiece: Quadruple revolving nosepiece, rotation on ball bearings. Centering system for each objective.

Objectives (strain-free):

– IOS W-PLAN POL 4x/0.10

– IOS W-PLAN POL 10x/0.25

– IOS W-PLAN POL 20x/0.45

– IOS W-PLAN POL 40x/0.65

All with anti-fungus treatment.

Specimen stage: Rotatable stage with locking mechanism and centering knobs. Vernier scale with accuracy 0.1 mm. Diameter 145 mm. Specimen slide clamps.

Focusing: Coaxial coarse (adjustable tension) and fine focusing mechanism with limit stop to prevent the contact between objective and specimen.

Condenser: Swing-out N.A. 0.2/0.9, with iris diaphragm, focusable and centerable. With rotating polarizing filter.

Transmitted illumination (Full Koehler type):  X-LED³ with white 3.6 W LED (6.300 K) withbrightness control. Multi-plug 100-240Vac/6Vdc external power supply.
